MEXA-1600D/DEGR-One Cabinet Analytical System for Direct Emissions Measurement

  Laboratory-grade analytical emissions system designed to measure raw exhaust gases from internal combustion engines. Single cabinet includes PC-based flow controller and sampling system as well as analyzers for measuring CO, CO₂, THC, NOx, O₂ and (optionally) EGR-CO₂. System is tailored to support R&D work on gasoline and diesel-fueled engines used in a variety of applications.

FEATURES

Self-contained system in minimal floor-space.

Easy-to-use PC-based flow controller with standard interfaces.

Bench is ISO-8178 complian.

Wide-range heated THC analyzer.

NOx analyzer is hot-dry/atmospheric type.

Minimum CO range is 100 ppm.

High performance:cost ratio due to standard global specification.

EGR option available.
